CHAPTER 1: INTRODUCTION
2003 IPMobileNet, Inc. 8 IPSeries MR User Manual / Rev. A / 04-September-03
Figure 3: External Features of an IPSeries Base Station (Front View)
The base station’s front external features consist of six (6) LED (light emitting diodes) indicators defined
as follows:
TABLE 3: EXTERNAL FEATURES (Front)
LED Name When lit….
TX Indicates that transmission is in progress
CD Carrier detect indicates an RF message is detected
RX1 Indicates that receiving is progress on Receiver 1
RX2 Indicates that receiving is progress on Receiver 2
RX3 Indicates that receiving is progress on Receiver 3
POWER Indicates the base station is powered on
