5.3 MODULES
1. RPS P25 (REPEATER POWER SUPPLY)
LEDs to indicate module status.
LED TYPE NORMAL
STATUS
FUNCTIÓN
SUPPLY Green On There are 26.4V at the RPS
P25 input
24V or 26.4V Green On There are 26.4V at the RPS
P25 output
13.2V Green On There are 13.2V at the RPS
P25 output
Power on switch (Ref. 7): ON/OFF switch to connect to and disconnect from the EZPRO25
RF
2. RPA P25 (REPEATER POWER AMPLIFIER)
LEDs to indicate module status.
LED TYPE NORMAL
STATUS
FUNCTIÓN
ON Green On Power supply correct
TX POWER Green On Module transmitting
3. RTX P25 (REPEATER TRANSMITTER)
LEDs to indicate module status.
LED TYPE NORMAL
STATUS
FUNCTIÓN
ON Green On Power supply correct
REF. ERROR Red Off Failure in the 10 MHz reference
INT. ERROR Red Off Internal failure
BBSR
ERROR
Red Off Communication failure with the
RCPU P25 module
RPA ERROR Red Off RPA P25 failure
RPW ERROR Red Off Reflected power failure
