User's Manual

Code: Installation Guide EZPRO25 RF.d
o
INSTALLATION
GUIDE
Date: 12/18/2007 Page: 5 of 21
Initial Release
Revision: 00
2. UNPACKING AND CHECKING
The following elements are supplied in the box:
EZPRO25 RF
2 cables SMB RF
Installation manual
The equipment is supplied with all the modules already assembled in the rack and with
the RF cables connected. The modules in the basic configuration are: Control (RCPU P25),
Transmitter (RTX P25), power module (RPA P25), Receiver (RRX P25) and the power supply module
(RPS P25).
IMPORTANT: if any of these elements is missing or damaged, contact your dealer and / or
installer.
3. PREVIOUS CONSIDERATIONS
This manual contains information on instructions for installation, maintenance and use. Read
the following pages before using this equipment.
It is inadvisable to switch on the equipment without having previously connected the antenna or, in
case of the EZPRO25 RF, the 50Ω load to the TNC connector. Doing so may seriously damage the
equipment and even cause irreparable damage to the transmitter circuits. It is important to use an
antenna adjusted to the work frequency.
4. INFORMATION ON SAFETY AND ELECTROMAGNETIC COMPATIBILITY
The equipment has been designed according to the following standards:
 ETSI ETS 300 392-2 - V2.5.2 (2005-11)
 ETSI ETS 300 394-1 - V2.4.0 (2005-10)
 ETSI EN 301 489-18 - V1.3.1 (2002-08)
 EN 60950-1 - 2001
 EN 60950-1:2001/A11:2004
 EN 60215-1989
 EN 60215:1989/A1:1992
 EN 60215:1989/A2:1994
