ON OFF
INTERNAL POWER SUPPLY FAILURE.
CONTACT TECHNICAL SERVICES.
REF ERROR ON Failure in the 10MHz reference. Check that the BSYNC
P25 module is installed or that the SYNC IN cable is
correctly connected. Contact Technical services if still
unsolved.
INT ERROR ON Internal failure. Contact Technical Services.
BBSR
ERROR
ON Communication failure by the EZPRO25 RF bus. Check
that all the modules are correctly installed. Contact
Technical services if still unsolved.
DIV ERROR ON Error in diversity: occurs when the difference in received
power between received paths exceeds a level (20 dBs
by default) for a consecutive number of receptions.
These receptions on the received paths which do not
have sufficient power are not counted.
This alarm does not disappear until there are no
receptions with the sufficient power, and until the
difference of received power between received paths
does not exceed the level previously mentioned.
Check diversity configuration in the CNC.
Check that the reception antennas are correctly
installed. Contact Technical services if still unsolved.
CNC ERROR ON Communication failure with the CNC. Check the
Ethernet connections.
Check that the CNC is working correctly. Contact
Technical Services if still unsolved.
RX Continuous
ON
Interference detection.
Check the installation. Check that the work frequencies
are correct.
ETH LINK1 OFF Failure in Ethernet link 1.
Check Ethernet connection 1 and the Switch A.
ETH LINK2 OFF Failure in Ethernet link 2.
Check Ethernet connection 2 and the Switch B.
ETH RX OFF Packets are not received by Ethernet.
Check the Ethernet connections.
RCPU P25
ETH TX OFF Packets are not sent by Ethernet.
Check the Ethernet connections.
