7. CONFIGURATION
A EZPRO25 RF is configured via an NMS (Network Management System). To configure the
EZPRO25 RF, consult the NMS manual.
8. INCIDENTS
The repeater must be repaired by authorized technical personnel only. If a EZPRO25
RF failure occurs, the entire EZPRO25 RF must be replaced. If transmitter module is
damaged and there is not an entire EZPRO25 RF available to replace, set RTX P25 and
RPA P25 modules previously calibrated jointly. In last case and if is not possible to carry out
one of the two previous options, replace one of these two modules and make the gain
calibration again.
If an error or alarm occurs in the EZPRO25 RF, this is indicated in the corresponding LED for
each one of the modules. The following list shows the possible failures and their solutions.
8.1 ALARMS
Led
indication
Status Failure / Solution
SUPPLY OFF
POWER SUPPLY FAILURE. CHECK THAT THE
SOURCE AND THE POWER SUPPLY CABLE
ARE CORRECTLY CONNECTED. CHECK THE
INTERNAL FUSE OF THE RPS P25. CONTACT
TECHNICAL SERVICES IF UNSOLVED.
24V or 26.4V OFF Power supply failure. Contact Technical services.
RPS P25
13.2V OFF Power supply failure. Contact Technical services.
RPA P25
ON OFF
POWER SUPPLY FAILURE. CONTACT
TECHNICAL SERVICES.
!
