5.4 CABLING AND CONNECTORS

♦ BSR75

8.- Power supply connector.

9.- Transmission power antenna connector.

10.- SMB RF cables.

11.- Reception antenna connector (receiver chain 1)

12.- Reception antenna connector (receiver chain 2)

13.- Reception antenna connectors for the RRX2 P25 option / antenna connectors for the

GPS, depending on the inserted module.

14.- Ethernet B connector.

15.- Ethernet A connector.

16.- SYNC IN2 connector.

17.- SYNC IN1 connector.

18.- SYNC OUT1 connector.

19.- SYNC OUT2 connector.

20.- Maintenance connector for BSR bus.

21.- Connector for VT100 for RCPU P25module maintenance.

22.- Connector for VT100 for RRX2 P25 module maintenance.

23.- Connector for VT100 for RRX1 P25 module maintenance.

24.- Connector for VT100 for RTX P25 module maintenance.

25.- TNC connector for 50Ω load.
