6. RCPU P25 (REPEATER CONTROL)
LEDs to indicate the module status.
LED TYPE NORMAL STATUS FUNCTIÓN
ON Green On Power supply correct
REF. ERROR Red Off Failure in the 10 MHz reference
INT. ERROR Red Off Internal failure
BBSR ERROR Red Off BSR bus failure
DIV ERROR Red Off Diversity failure
CNC ERROR Red Off Communication failure with the CNC
AUX Green Off Not used
MCCH Green Off / On Main carrier indicator
RX Green Flickering APCO P25 information received
TX Green On APCO P25 information transmission
ETH LINK1 Yellow On Link between the local network switch and
the RCPU P25 module in Ethernet port 1
ETH LINK2 Yellow Off Link between the local network switch and
the RCPU P25 module in Ethernet port 1
ETH RX Green Flashing Reception of an Ethernet packet
ETH TX Green Flashing Transmission of an Ethernet packet
