Integration Instructions

- Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B) / NMB-3 (B)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003.
List of applicable FCC rules
- Part 15 Subpart C
Summary of the specific operational use conditions
The Bluetooth Low energy module ASM11374 is built on the BT chip nRF52832 from Nordic
semiconductor. The module is using an omni-directional antenna, no limitation needs to be remarked.
Limited module procedures
N/A
Trace antenna designs
Since the antenna is a part of the module, it is not allowed to change the antenna.
Antennas
This radio transmitter has been approved by FCC and ISED to operate with the antenna types listed below
with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Type
Max Gain
folded curved quarter wave monopole
-0.5 dBi
Le présent émetteur radio a été approuvé par ISDE pour fonctionner avec les types d'antenne énumérés
ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le
gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
Type
Gain maximal
folded curved quarter wave monopole
-0.5 dBi
Label and compliance information
The host device shall be properly labelled to identify the modules within the host device. The certification
label of the module shall be clearly visible at all times when installed in the host device, otherwise the host
device must be labelled to display the FCC ID and IC of the module, preceded by the words "Contains
transmitter module", or the word "Contains", or similar wording expressing the same meaning, as follows:
Contains FCC ID: 2AUGTASM17360
Contains IC: 25405-ASM17360
L’équipement hôte doit être correctement étiqueté pour identifier les modules dans l’équipement. L'étiquette
de certification du module doit être clairement visible en tout temps lorsqu'il est installé dans l'hôte,
l’équipement hôte doit être étiqueté pour afficher le FCC ID et IC du module, précédé des mots "Contient le
module émetteur", ou le mot "Contient", ou un libellé similaire exprimant la même signification, comme suit:
