ISM14585-EVB User’s Manual
DOC-DS-14585-EVB-201911-3.6
Confidential Inventek Systems
Page 6
3.2 Dialog’s DA14585-00ATDEVKT-P Development Kit – Pro Motherboard
EVK and SDK SmartSnippets Studio
The Dialog’s SDK SmartSnippets Studio includes all of the support required for the tool
chain, build system, the BLE driver and the software stack together with example
applications. The SDK also runs on Windows.
The ISM14585-EVB provides a platform for the design and development of applications to
run on the ISM14585-L35-P8 SiP Module.
3.3 Feature Highlights:
The ISM14585-L35-P8 SiP Module integrates the Dialog DA14585 BLE 5.0
radio SoC, 8Mbit SPI Flash, a Cortex M0 ARM-based 32-bit 16MHz, 96kB
Data/Retention SRAM, 128kB ROM. 64kB One-Time-Programmable (OTP)
memory, a PMU, and a Power Amplifier.
Complies with Bluetooth V5.0 solution and includes the ISM14585-L35-P8
SiP Module, integrated Antenna or the option for a w.fl RF connector.
Applications are downloaded to the ISM14585-L35-P8 SiP Module and
debugged via the Dialog DA14585 Development Kit-Pro Motherboard (P/N
DA14585-00ATDEVKT-P)
A UART on the ISM14585-L35-P8 SiP Module connects to the ISM14585-
L35-P8-EVB Daughterboard which connects to the Dialog DA14585
Development Kit-Pro Motherboard. The USB-serial interface is used to
enable serial communications with a PC terminal application.
The ISM14585-EVB Daughterboard is powered from the Dialog DA14585
Development Kit-Pro Motherboard.
• Voice-controlled remote controls,
• Beacons, (Mulit-sensor)
• Wearable devices: Fitness trackers, Consumer health
• Smartwatches
• Human interface devices: Keyboard, Mouse
• Toys
• Consumer appliances.
