Page 13
POOL SETUP (continued)
• Nextslidetheverticallegsintothebeltlooplocatedinthemiddleof
the pool liner. Carefully slide the leg into the belt loop and insert the
 topofthelegintothebottomofthejoint.Snapthislegintojoint’s
holes by aligning the holes and the spring-loaded pin. Attach the
 leg’sendcap
(5)
to the bottom of the leg
(see drawings 3)
.
• Uponconnectingthelastleg,grabholdoftheframepool’stopbeams
 in2–3locations.Shakethepooltobesurethatallthejoints,legs
and beams fit into each other. Ensure that all pins are in position by
pushing them downwards through the holes
(see drawing 4.1)
.
• Pullgently,inanoutwarddirection,thebottomofthelegmakingsure
the leg is vertical and perpendicular to the level ground.
3. Filling of the pool
• Thefollowingappliestopoolliners
with
hoseconnectors(16’(488cm)&belowpools).Ifthepoolwas 
purchased
without
a filter pump, insert the strainer hole plugs
(11)
intotheblackfilterpumpoutlets.Do 
this from the inside of the pool so that water will not run out when filling it. If the pool was purchased
with
afilterpump,readtheKrystalClear™FilterPumpManualfirstand
then
proceed to next installation
step.
• Beforefillingthepoolwithwater,ensurethatthedrainpluginsidethepoolisclosedandthatthedrain 
 capontheoutsideisscrewedontightly.Fillthepoolwithnomorethan1inch(2.5cm)ofwater.Check 
to see whether the water is level.
IMPORTANT: If the water in the pool flows to one side, the pool is not completely level. Setting
up the pool on unlevel ground will cause the pool to tilt resulting in the sidewall material bulging
and a potential collapse of the pool. If the pool is not completely level, you must drain the pool,
level the area or move the pool to a different area that is level, and re-fill the pool, following the
above directions.
• Smoothoutthebottomlinerwrinkles(frominsidethepool)bypushingoutwherethepoolfloorandpool
 sidesmeet.Or,(fromoutsidepool)reachunderthesideofthepool,graspthepoolfloorandpullin 
an outward direction. If the ground cloth is causing the wrinkles, have 2 people pull from opposite sides to
remove all wrinkles. Use the properly assembled pool ladder when entering or exiting the pool during this
process.
• Fillthepoolwithwateruptojustbelowthesleeveline.
(see drawing 4.2)
.
4
.
Posting aquatic safety signs
 SelectahighlyvisibleareanearthepooltoposttheDanger
 NoDivingorJumpingsignincludedlaterinthismanual.
4.2
FILL LINE
3
8
5
3
4.1
