Operation Manual

315
PO
SAVE THESE INSTRUCTIONS
English
(315PO) PRISM FRAME
TM
POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016
Page 10
REF
NO.
DESCRIPTION
POOL SIZE & QUANTITIES
10’
(305cm)
12’
(366cm)
13’
(396cm)
14’
(427cm)
15’
(457cm)
16’
(488cm)
18’
(549cm)
24’
(732cm)
1 PIN(WITH2EXTRA) 22 26 28 30 32 34 38 50
2 SEAL(WITH2EXTRA) 22 26 28 30 32 34 38 50
3 T - JOINT 10 12 13 14 15 16 18 24
4 SPRINGPIN 10 12 13 14 15 16 18 24
5 LEGCAP 10 12 13 14 15 16 18 24
6 HORIZONTALBEAM 10 12 13 14 15 16 18 24
7 POOLLINER(DRAINVALVECAPINCLUDED) 1 1 1 1 1 1 1 1
8 VERTICALLEG(SPRINGPININCLUDED) 10 12 13 14 15 16 18 24
9 DRAINVALVECAP
1 1
1 1 1 1 2 2
10 GROUNDCLOTH(OPTIONAL) 1 1 1 1
11 STRAINERHOLEPLUG(OPTIONAL,WITH1EXTRA) 3 3 3 3 3 3
12 DRAINCONNECTOR 1 1 1 1 1 1 1 1
13 POOLCOVER(OPTIONAL) 1 1 1 1 1 1
REF
NO.
DESCRIPTION
10’ X 30”
(305cm X 76cm)
12’ X 30”
(366cm X 76cm)
12’ X 33”
(366cm X 84cm)
12’ X 39”
(366cm X 99cm)
13’ X 39”
(396cm X 99cm)
14 X 42”
(427cm X 107cm)
SPARE PART NO.
1 PIN(WITH2EXTRA) 10312 10312 10312 10312 12136 12136
2 SEAL(WITH2EXTRA) 10648 10648 10648 10648 10648 10648
3 T - JOINT 12451 12452 12452 12452 12462 12462
4 SPRINGPIN 12453 12453 12453 12453 12464 12464
5 LEGCAP 12454 12454 12454 12454 12465 12465
6 HORIZONTALBEAM 12118 12118 12118 12118 12458 12458
7 POOLLINER(DRAINVALVECAPINCLUDED) 12448 12449 12532 12533 12534 12466
8 VERTICALLEG(SPRINGPININCLUDED) 12450 12450 12537 12538 12540 12460
9 DRAINVALVECAP 10649 10649 10649 10649 10649 10649
10 GROUNDCLOTH(OPTIONAL)
11 STRAINERHOLEPLUG(WITH1EXTRA) 10127 10127 10127 10127 10127 10127
12 DRAINCONNECTOR 10184 10184 10184 10184 10184 10184
13 POOLCOVER(OPTIONAL) 11142 11054
REF
NO.
DESCRIPTION
15’ X 33”
(457cm X 84cm)
15’ X 36”
(457cm X 91cm)
15’ X 42”
(457cm X 107cm)
15’ X 48”
(457cm X 122cm)
16’ X 48”
(488cm X 122cm)
18’ X 48”
(549cm X 122cm)
24’ X 52”
(732cm X 132cm)
SPARE PART NO.
1 PIN(WITH2EXTRA) 12136 12136 12136 12136 12136 12536 12536
2 SEAL(WITH2EXTRA) 10648 10648 10648 10648 10648 10648 10648
3 T - JOINT 12463 12463 12463 12463 12463 12472 12474
4 SPRINGPIN 12464 12464 12464 12464 12464 12475 12475
5 LEGCAP 12465 12465 12465 12465 12465 12476 12476
6 HORIZONTALBEAM 12458 12458 12458 12458 12458 12470 12470
7 POOLLINER(DRAINVALVECAPINCLUDED) 12455 12535 12456 12457 12467 12468 12469
8 VERTICALLEG(SPRINGPININCLUDED) 12459 12541 12460 12461 12461 12471 12473
9 DRAINVALVECAP 10649 10649 11044 11044 11044 11044 11044
10 GROUNDCLOTH(OPTIONAL) 18932 18932 18932 18932 18927 18933 18935
11 STRAINERHOLEPLUG(WITH1EXTRA) 10127 10127 10127 10127 10127
12 DRAINCONNECTOR 10184 10184 10184 10184 10184 10184 10184
13 POOLCOVER(OPTIONAL) 18901 18901 18901 18901 10754 18937 18929
