(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 OWNER’S MANUAL English 315 PO IMPORTANT SAFETY RULES Read, understand, and follow all instructions carefully before installing and using this product. Prism Frame Pool 10' - 24' (305 cm - 732 cm) models TM For illustrative purposes only. Accessories may not be provided with pool.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English TABLE OF CONTENTS Warnings......................................................................................... 3-5 Parts References............................................................................ 6-10 Setup Instructions.......................................................................... 11-13 General Aquatic Safety..................................................................
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. WARNING • Continuous and competent adult supervision of children and the disabled is required at all times. • Secure all doors, windows and safety barriers to prevent unauthorized, unintentional or unsupervised pool entry.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO IMPORTANT SAFETY RULES Read and follow all safety information and instructions. Keep for future reference. Failure to follow these warnings and instructions can result in serious injury or death to users, especially children.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English Barriers for Residential Swimming Pool Guidelines: An outdoor swimming pool, including an inground, aboveground, or onground pool, hot tub, or spa, should be provided with a barrier which complies with the following: 1. The top of the barrier should be at least 48 inches above grade measured on the side of the barrier which faces away from the swimming pool.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 315 PO English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. For Pools with Dual Suction Outlets Configuration: In order to comply with the requirement of the Virginia Grahame Baker Act (for USA and Canada), your pool is designed with dual suction outlets and one inlet fittings.
SAVE THESE INSTRUCTIONS SPLIT HOSE PLUNGER VALVE INLET STRAINER CONNECTOR AIR JET VALVE POOL INLET AIR ADAPTOR + AIR JET VALVE CAP (NOT SHOWN) PIN (WITH 2 EXTRA) SEAL (WITH 2 EXTRA) T - JOINT SPRING PIN LEG CAP HORIZONTAL BEAM POOL LINER (DRAIN VALVE CAP INCLUDED) VERTICAL LEG (SPRING PIN INCLUDED) DRAIN VALVE CAP GROUND CLOTH STRAINER HOLE PLUG DRAIN CONNECTOR POOL COVER HOSE HOSE T-JOINT HOSE CLAMP STRAINER CONNECTOR STRAINER GRID POOL INLET JET NOZZLE HOSE O-RING PLUNGER VALVE (HOSE O-RING & STEP WASHE
SAVE THESE INSTRUCTIONS PIN (WITH 2 EXTRA) SEAL (WITH 2 EXTRA) T - JOINT SPRING PIN LEG CAP HORIZONTAL BEAM POOL LINER (DRAIN VALVE CAP INCLUDED) VERTICAL LEG (SPRING PIN INCLUDED) DRAIN VALVE CAP GROUND CLOTH STRAINER HOLE PLUG DRAIN CONNECTOR POOL COVER HOSE HOSE T-JOINT HOSE CLAMP STRAINER CONNECTOR STRAINER GRID POOL INLET JET NOZZLE HOSE O-RING PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) STEP WASHER STRAINER NUT FLAT STRAINER RUBBER WASHER DESCRIPTION 10312 10648 12452 12453 12454 12118 12449E
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Non-USA & Canada: 12 13 1 9 2 3 4 6 11 7 10 8 5 16’ (488 cm) and below 12 13 1 9 2 3 4 6 5 7 8 10 18’ (549 cm) and above NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English REF NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 REF NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 REF NO.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO POOL SETUP IMPORTANT SITE SELECTION AND GROUND PREPARATION INFORMATION WARNING • • • • • The pool location must allow you to secure all doors, windows, and safety barriers to prevent unauthorized, unintentional or unsupervised pool entry. Install a safety barrier that will eliminate access to the pool for young children and pets.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO POOL SETUP (continued) You may have purchased this pool with the Intex Krystal Clear™ filter pump. The pump has its own separate set of installation instructions. First assemble your pool unit and then set up the filter pump. Estimated assembly time 30-60 minutes. (Note the assembly time is only approximate and individual assembly experience may vary.) 1.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO POOL SETUP (continued) • Next slide the vertical legs into the belt loop located in the middle of the pool liner. Carefully slide the leg into the belt loop and insert the top of the leg into the bottom of the joint. Snap this leg into joint’s holes by aligning the holes and the spring-loaded pin. Attach the leg’s end cap (5) to the bottom of the leg (see drawings 3).
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions. Remember, however, that product warnings, instructions and safety guidelines cover some common risks of water recreation, but do not cover all risks and dangers.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO POOL MAINTENANCE & CHEMICALS WARNING REMEMBER TO • Protect all pool occupants from possible water-related illnesses by keeping the pool water clean and sanitized. Do not swallow the pool water. Always practice good hygiene. • Keep your pool clean and clear. The pool floor must be visible at all times from the outside barrier of the pool.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO POOL MAINTENANCE & DRAINAGE CAUTION ALWAYS FOLLOW THE CHEMICAL MANUFACTURER'S DIRECTIONS, AND THE HEALTH AND HAZARD WARNINGS. Do not add chemicals if the pool is occupied. This can cause skin or eye irritation. Concentrated chlorine solutions can damage the pool liner. In no event is Intex Recreation Corp., Intex Development Co. Ltd.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO WINTER PREPARATIONS Winterizing your Above Ground Pool After usage, you can easily empty and store away your pool in a safe place. You must drain, disassemble and properly store the pool when the temperature drops below 41 degrees Fahrenheit (5 degrees Celsius) to prevent ice damage to the pool and related components. Ice damage can result in sudden liner failure or pool collapse.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO TROUBLESHOOTING PROBLEM DESCRIPTION CAUSE SOLUTION ALGAE • Greenish water. • Chlorine and pH • Green or black spots level need on pool liner. adjustment. • Pool liner is slippery and/or has a bad odor. • Super chlorinate with shock treatment. Correct pH to your pool store’s recommended level. • Vacuum pool bottom. • Maintain proper chlorine level.
(315PO) PRISM FRAMETM POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2016 English 315 PO LIMITED WARRANTY Your Intex Pool has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies to the Intex Pool only. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable.
