User's Manual Part 3

Intermec EasyCoder F4 – Installation & Operation Ed. 2
Appendix 5 RFID Module
RFID Module
The EasyCoder F4 can optionally be fitted with an Intellitag
®
500 RFID (radio
frequency identification) board that provides the printer with the means to pre-
program Intellitag
®
500 RFID SmartLabels when the bar code portion of the label is
printed.
The RFID board is addressed in Intermec Fingerprint 7.3 or later as device “uart2:”
The RFID board does not require connection to any device external to the printer.
The RFID module is fitted in the printer in the space allocated for optional interface
boards and therefore cannot be used in conjuction with, or in addition to, any of the
optional interface boards.
Refer to the installation instructions for the RFID Option Board for further
information.
Chassis location for RFID module
112
