User's Manual Part 3

Appendix 1 Technical Data
88 Intermec EasyCoder F4 – Installation & Operation Ed.2
Technical Data, cont’d.
Sensors
Label Gap/Black Mark/Out of Paper Yes 5 fixed positions
Printhead Lifted Yes
Controls
Control Lamps 3
Display 2 x 16 character LCD w. background light
Keyboard 22 keys membrane switch type
Print Button 1
Beeper Yes
Data Interfaces
Serial 1 x RS 232C + 1 x USB
Bar Code Wand Yes
Electronic Keys 2 For setup
Connection for Optional Interface Boards
1 Future option
Memory Card Adapter 1
Accessories and Options Flash or SRAM cards
RFID Module Option
Rewind Unit Option For peel-off operation
Paper Supply Spool Option Replaces hanger
3” Adapter for Paper Supply Spool Option
Short Side Door Option
3
Long Side Door Option
3
Label Taken Sensor Option
Real-Time Clock Option 10+ years life
Quick-Load Guides Standard
Fitted in some models
RS 232C Cable Option
EasySet Bar Code Wand Option For quick setup
Parallel Interface Board Option IEEE 1284
Double Serial Interface Board Option
Industrial Interface Board Option
EasyLAN 100I Interface Board Option Ethernet
External Alphanumeric Keyboard Option
Flash Memory Cards Option
= 64 Mbit (8 MB)
Electronic Keys Option
1. The max. print length is also restricted by the amount of free DRAM memory.
2. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3. Depending on model, the printer may be delivered with either a long or a short side door.
