Appendix 1
Printing
Print Technique Direct Thermal
Printhead Resolution 8 dots/mm (203.2 dpi)
Print Speed (variable) 100 – 200 mm/sec. (≈ 4 – 8"/sec.)
Print Width (max) 104 mm (4.095") = 832 dots
Print Length (max) 32767 dots = 409.5 cm
1
Media Width (min/max) 25 – 114.3 mm (1 –4.5") Standard paper guide
Media Width (min/max) 40 – 114.3 mm (1.57 – 4.5") Quick-Load guides
Paper Roll Diameter (max) 213 mm (8.38") Short door/no rewind
Paper Roll Core Diameter 38 – 40 mm (1.5") or 76 mm (3")
Print Directions 4
Modes of Operation
Tear Off Yes
Peel Off Optional Requires Rewind Unit
Firmware
Operating System Intermec Fingerprint 7.31 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Built-in scalable fonts (std) 15 Unicode fonts
2
Built-in bar code symbologies (std) 36
Startup Program (std) Intermec Shell 4.4
Physical Measures
Dimensions (W x L x H) 244 x 397 x 178 mm (9.61 x 15.63 x 7.00") w. Long side door
Weight (excluding media) ≈ 7 kgs (15.5 lbs) Depending on model
Ambient Operating Temperature +5°C – +40° C (+41°F – +104° F)
Humidity 20 –80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 1 – 2 Std. 1 x 2 Mbytes
On-board DRAM SIMM 1 Std. 4 Mbytes
Real-Time Clock Option 10+ years life
Power Supply
Mains Voltage >90 – <264 V AC, 45 – 65 Hz
PFC Regulation IEC 61000-3-2
Maximum Power Consumption Continuous 140 W; Peek 300W
Technical Data
