126 TruVision NVR 20 User Manual
Possible Camera Configurations: Using Mixed Camera
Types
Model
Examples for Mixed Camera Types
-Standard Definition and 2.0Mpx Cameras
16 Channel 8 Channel
# of VGA/4CIF cams/encoders 16 12 8 4 0 8 4 0
# of 2.0 Mpx cams** 0 1 2 4 4 0 1 2
Total cameras
16 13 10 8 4 8 5 2
Recommended Storage*
10 days 4TB 2TB
20 days
8TB 4TB
40 days 16TB 8TB
** Additional performance possible When using TruVision 2.0 Mpx Cameras
# of 2.0 Mpx cams
12.5fps/15fps or fewer, Bit Rate: 4Mpbs
0 2 4 6 8 0 2 4
*Storage estimates based on settings below and may vary by actual configuration and installation.
VGA/4CIF
25fps/30fps, Bit Rate: 2Mbps
1.3 Mpx
25fps/30fps, Bit Rate: 4Mpbs
2.0 Mpx
12.5fps/15fps, Bit Rate: 4Mpbs
Model
Examples For
Mixed Camera
Types
-Standard
Definition and
1.3Mpx Cameras
16 Channel 8 Channel
# of VGA/4CIF
cams/encoders
16 14 12 10 8 6 4 2 0 8 6 4 2 0
# of 1.3Mpx cams 0 1 2 3 4 5 6 8 8 0 1 2 3 4
Total cameras 16 15 14 13 12 11 10 10 8 87 6 5 4
Recommended
Storage*
10 days 4TB 2TB
20 days 8TB 4TB
40 days 16TB 8TB
