TruVision NVR 20 User Manual 121
Video motion detection Motion Detection is provided directly at the IP Camera
Manufacturer and capabilities vary by Manufacturer
Operation
Operating system Linux
Languages English
Users 3-Levels: Admin, Operator & Guest
Multiple Users may be assigned to each level
Network
Type 10/100/1000 Base-T, RJ-45
Protocol TCP, IP, UDP, ARP, RARP, PPP, PPPoE, DHCP,SNMP
Others ADSL modem and PSTN line for alarm video transmission
e-SATA Future Use
Archive
Audio and video USB2.0
Connectors
RS-232 serial port RJ-45 (Troubleshooting Only)
RS-485 control port Future Use
USB 2, USB 2+ (Unit Front)
Alarm handling
Alarm input 16 programmable NO/NC
Alarm output Form C alarm relay (4)
Miscellaneous
Input voltage 100-240VAC, 6.3A, 50-60Hz
Power consumption 20W (with no HDDs)
Operating temperature 0 to +40°C
Relative humidity 10 to 90% (non-condensing)
Dimensions (W x H x D) 17.72" x 17.72" x 3.74" (450mm x 450mm x 95mm), 19" (2U)
Weight
20.44 lbs (9.27kg) with no drives
21.98 lbs (9.97kg) to 32.79 lbs (14.87kg) with 1 - 16 drives
depending on model.
Mounting Rack mount ears included
Remote Browser requirements TVN 20 Browser
Intel-based PC Minimum: Intel E6550 Dual Core class Processor at 2.33 Ghz
(4MB Cache)
Recommended: Intel Core I5 750 Quad Core class Processor at
2.66 Ghz (8MB Cache)
