KTP-24-8 Multiple Output Power Supply Installation Instructions

OPERATION

Table 1. Maximum cable length

Maximum Cable Length

Wire Gauge

All Domes

without Heater/Fan

(20VA)

10 2.60 3000 915

12 2.05 1900 580

14 1.62 1200 365

16 1.29 750 230

18 1.02 465 142

20 0.81 290 90

22 0.64 185 56

Each 24 VAC output of the power supply has a resettable fuse that will trip

if the current draw exceeds one amp. In this event, the device on that

output may operate intermittently, or not at all. The fuse will automatically

reset itself when the load is removed from the output.

CAUTION:

Do not reconnect any device that caused an output fuse to trip until

the device has been inspected and determined to be in proper

working condition.
