User Manual

Web Managed GbE Switch
72
3.5.4 ACL Policy Setting
The following table describes the labels on this screen.
LABEL DESCRIPTION
Policy Index You can choose the policy index.
Get To get the basic information of the policy index.
VLAN ID Enter a VLAN ID.
Port Number Enter a port number
Action Select the action to take:
 Mirror Index: mirror the packet via the configuration of the
specified mirror index.
 Rate Limit: limit the packet rate 7he LQFUHPHQW is 16kbps.
 Priority: change the packet priority.
Apply Click Apply to save your changes to the switch.
3.6 QoS
Use the QoS pages to configure settings for the switch QoS interface and how the switch connects
to a remote server to get services.
3.6.1 Port-based Priority
You can configure the switch to assign an IEEE 802.1p priority to packets based on the ingress
(incoming) port of the packet.
Click QoS > Port-based Priority in the navigation panel to display the screen shown below.
