The following table describes the labels on this screen.
LABEL
DESCRIPTION
Port Select
Select the port(s) that will use MST setting.
MST ID
You can manually set the MST ID to specify MST instance.
Internal Path
Cost
You can manually set the internal path cost to the selected ports in the
specified MST instance. (0 means “Auto”)
Priority
You can manually set the priority to the selected ports in the specified MST
instance.
Apply
Click Apply to save your changes to the switch.
Port
It displays the port you have chosen.
MSTI ID
It displays the MSTI ID of the chosen port.
Designed
Bridge
It displays the designed bridge of the chosen port.
