90 Voice API Programming Guide — June 2005
Recording and Playback
Note: On DM3 boards, not all voice coders are available on all boards. The availability of a voice coder
depends on the media load chosen for your board. For a comprehensive list of voice coders
supported by each board, see the Release Guide for your system release. For details on media
loads, see the Configuration Guide for your product family.
The voice encoding methods supported on Springware boards are listed in Table 10.
Table 9. Voice Encoding Methods (DM3)
Digitizing Method
Sampling Rate
(kHz)
Resolution (Bits) Bit Rate (Kbps) File Format
OKI ADPCM
6 4 24 VOX, WAVE
OKI ADPCM 8 4 32 VOX, WAVE
IMA ADPCM 8 4 32 VOX, WAVE
G.711 PCM
A-law and mu-law
6 8 48 VOX, WAVE
G.711 PCM
A-law and mu-law
8 8 64 VOX, WAVE
G.721 8 4 32 VOX, WAVE
Linear PCM
8 8 64 VOX, WAVE
Linear PCM 8 16 128 VOX, WAVE
Linear PCM
11 8 88 VOX, WAVE
Linear PCM 11 16 176 VOX, WAVE
TrueSpeech 8 16 8.5 VOX, WAVE
GSM 6.10 full rate
(Microsoft format)
8 (value ignored) 13 VOX, WAVE
GSM 6.10 full rate
(TIPHON format)
8 (value ignored) 13 VOX
G.726 bit exact 8 2 16 VOX, WAVE
G.726 bit exact 8 3 24 VOX, WAVE
G.726 bit exact 8 4 32 VOX, WAVE
G.726 bit exact 8 5 40 VOX, WAVE
