Figure 5. Call Outcomes for Call Progress Analysis (Springware)
7.10.6 Obtaining Additional Call Outcome Information
To obtain additional call progress analysis information, use the following extended attribute
functions:
ATDX_ANSRSIZ( )
Returns duration of answer.
ATDX_CPERROR( )
Returns call analysis error.
ATDX_CPTERM( )
Returns last call analysis termination.
ATDX_CONNTYPE( )
Returns connection type
ATDX_CRTNID( )
Returns the identifier of the tone that caused the most recent call progress analysis termination.
ATDX_DTNFAIL( )
Returns the dial tone character that indicates which dial tone call progress analysis failed to
detect.
ATDX_FRQDUR( )
Returns duration of first frequency detected.
ATDX_FRQDUR2( )
Returns duration of second frequency detected.
Frequency
Detection
Cadence
Detection
Loop
Current
Detection
Positive
Voice or
Answering
Machine
Detection
Incoming
Signal
Connect
Reason
Termination Reason: From ATDX_CPTERM( ).
Connect Reason: From ATDX_CONNTYPE( ).
CR_CAD
CON_LPC
CON_PVD
CON_PAMD
Termination
Reason
Connect
CR_CNCT
No
Ringback
CR_NORB
Busy
CR_BUSY
Faxtone
CR_FAXTONE
Intercept
(SIT)
CR_CEPT
No
Dialtone
CR_NO-
DIALTONE
No
Answer
CR_NOANS
