154 Voice API Programming Guide — June 2005

Global Tone Detection and Generation, and Cadenced Tone Generation

analysis creates 8 GTD tones; this uses 17 memory blocks on each channel on which it is

activated.

• On Springware boards, if you use call progress analysis to identify tri-tone special information

tone (SIT) sequences, call progress analysis creates GTD tones, which reduces the number of

user-defined tones you can create. Call progress analysis creates one GTD tone template for

each single frequency tone that you define in the DX_CAP structure. For example, if detecting

the SIT sequences per channel (3 frequencies), the GTD memory will be reduced by 5 blocks.

• On Springware boards, if you initiate call progress analysis and there is not enough memory to

create the GTD tones, you will get an EDX_MAXTMPLT error. This indicates that you are

trying to exceed the maximum number of GTD tones.

• On Springware boards, if you use a build tone function (such as dx_blddt( ) or

r2_creatfsig( )) to define a user-defined tone that alone or with existing user-defined tones

exceeds the available memory, you will get an EDX_MAXTMPLT error.

• On Springware boards on Linux, call progress analysis SIT detection releases GTD memory

when call progress analysis has completed. The other features do not release GTD memory

until a dx_deltones( ) is performed.

• On Springware boards on Linux, if you initiate call progress analysis and there is not enough

memory to create the SIT sequences internally, you will get a T_CAERROR event and the

evtdata field will contain MEMERR. On Springware boards on Windows, if you initiate call

progress analysis and there is not enough memory to create the SIT sequences internally, you

will get a CR_MEMERR.

• The dx_deltones( ) function deletes all user-defined tones from a specified channel and

releases the memory that was used for those user-defined tones. When an associated ASCII

digit is specified, tone events will not be generated for that tone.

• If you create R2/MF user-defined tones using r2_creatfsig( ), the voice boards are usually able

to create all 15 R2/MF user-defined tones due to the overlap in frequencies for the R2/MF

signals. If these boards do not have sufficient memory, they may be able to support R2/MF

signaling through a reduced number of R2/MF user-defined tones.

The r2_creatfsig( ) function is not supported on DM3 boards.

• Voice boards support a full set of inbound or outbound R2/MF signals, or the complete Socotel

signal set.

Table 18 lists the maximum number of tone templates for dual tones available on Springware

boards.

For information on maximum amount of memory available for tone templates on Springware

boards, see Table 16, “Maximum Memory Available for User-Defined Tone Templates

(Springware)”, on page 152 and Table 17, “Maximum Memory Available for Tone Templates for

Tone-Creating Voice Features (Springware)”, on page 152.

Table 18. Maximum Tone Templates for Dual Tones (Springware)

Hardware

Tone Templates

Per Board

Tone Templates

Per Channel

D/41JCT-LS 33 8
