Voice API Programming Guide — June 2005 147
13
13.Global Tone Detection and
Generation, and Cadenced Tone
Generation
This chapter discusses global tone detection (GTD), global tone generation (GTG), and cadenced
tone generation:
• Global Tone Detection (GTD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
• Global Tone Generation (GTG). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
• Cadenced Tone Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
13.1 Global Tone Detection (GTD)
Global tone detection (GTD) is described in the following sections:
• Overview of Global Tone Detection
• Global Tone Detection on DM3 Boards versus Springware Boards
• Defining Global Tone Detection Tones
• Building Tone Templates
• Working with Tone Templates
• Retrieving Tone Events
• Setting GTD Tones as Termination Conditions
• Maximum Amount of Memory for Tone Templates
• Estimating Memory
• Guidelines for Creating User-Defined Tones
• Global Tone Detection Application
13.1.1 Overview of Global Tone Detection
Global tone detection (GTD) allows you to define single or dual frequency tones for detection. The
characteristics of a tone are defined in a GTD tone template. A tone template contains parameters
that allow you to assign frequency bounds and cadence components. GTD can detect single and
dual frequency tones by comparing all incoming sounds to the GTD tone templates. Global tone
detection and GTD tones are also known as user-defined tone detection and user-defined tones.
The typical use of global tone detection is to detect single and dual frequency tones other than
those automatically provided with the voice software. This includes tones outside the standard
