Advanced
Processor Configuration
Core Count <Total Number of Cores>
Core Frequency <Current Processor Frequency>
System Bus Frequency <Current FSB Frequency>
Enhanced Intel
®
SpeedStep Tech Enabled/Disabled
Core Multi-processing Enabled/Disabled
Intel
®
Virtualization Technology Enabled/ Disabled
Intel
®
VT for Directed I/O
Enabled/Disabled
Simulated MSI Support Enabled/Disabled
Execute Disable Bit Enabled/Disabled
Hardware Prefetcher Enabled/Disabled
Adjacent cache line prefetch Enabled/Disabled
Processor Re-Test Enabled/Disabled
► Processor 1 Information
► Processor 2 Information
Figure 18. Setup Utility — Processor Configuration Screen Display
Table 31. Setup Utility — Processor Configuration Screen Fields
Setup Item Options Help Text Comments
Core Count
Information only. Total
number of processor cores in
the system.
Core Frequency
Information only. Frequency
at which processors currently
run.
System Bus Frequency
Information only. Current
frequency of the processor
front-side bus.
Enhanced Intel
®
SpeedStep Technology
Enabled
Disabled
Enhanced Intel SpeedStep
®
Technology
allows the system to dynamically adjust
processor voltage and core frequency, which
can result in decreased average power
consumption and decreased average heat
production.
Contact your OS vendor regarding OS
support of this feature.
