System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
80
Setup Item Options Help Text Comments
System Time [HH:MM:SS] System Time has configurable
fields for Hours, Minutes, and
Seconds.
Hours are in 24-hour format.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
5.2.3.2 Advanced Screen
The Advanced screen provides an access point to configure several options. On this screen, the
user selects the option that is to be configured. Configurations are performed on the selected
screen, and not directly on the Advanced screen.
To access this screen from the Main screen, press the right arrow until the Advanced screen is
chosen.
Main
Advance
d
Security Server Management Boot Options Boot Manager
► Processor Configuration
► Memory Configuration
► ATA Controller Configuration
► Mass Storage Controller Configuration
► Serial Port Configuration
► USB Configuration
► PCI Configuration
► System Acoustic and Performance Configuration
Figure 17. Setup Utility — Advanced Screen Display
