5.2.3.1 Main Screen
The Main screen is the screen that is first displayed when the BIOS Setup is entered, unless an
error has occurred. If an error has occurred, the Error Manager screen is displayed instead.
Main
Advance
d
Security Server Management Boot Options Boot Manager
Logged in as <Administrator or User>
Platform ID
<Platform Identification String>
System BIOS
Version S5400.86B.xx.yy.zzzz
Build Date <MM/DD/YYYY>
Processor
Intel
®
Xeon
®
CPU
Core Frequency <Current Operating Frequency>
Count <#>
Memory
Size <How much memory is installed>
Quiet Boot Enabled/Disabled
POST Error Pause Enabled/Disabled
System Date <Current Date>
System Time <Current Time>
Figure 16. Setup Utility — Main Screen Display
