Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
77
Key Option Description
<F10> Save and Exit Pressing <F10> causes the following message to appear:
Save configuration and reset?
Yes No
If “Yes” is highlighted and <Enter> is pressed, all changes are saved and the Setup
is exited. If “No” is highlighted and <Enter> is pressed, or the <Esc> key is pressed,
the user is returned to where they were before <F10> was pressed without affecting
any existing values.
5.2.2.5 Menu Selection Bar
The Menu Selection Bar is located at the top of the BIOS Setup Utility screen. It displays the
major menu selections available to the user. By using the left and right arrow keys, the user can
select the menus listed here. Some menus are hidden and become available by scrolling off the
left or right of the current selections.
5.2.3 Server Platform Setup Utility Screens
The following sections describe the screens available for the configuration of a server platform.
In these sections, tables are used to describe the contents of each screen. These tables follow
the following guidelines:
The Setup Item, Options, and Help Text columns in the tables document the text and
values that are also displayed on the BIOS Setup screens.
In the Options column, the default values are displayed in bold. These values are not
displayed in bold on the BIOS Setup screen. The bold text in this document is to serve
as a reference point.
The Comments column provides additional information where it may be helpful. This
information does not appear on the BIOS Setup screens.
Information that is enclosed in brackets (< >) in the screen shots identifies text that can
vary, depending on the option(s) installed. For example <Current Date> is replaced by
the actual current date.
Information that is enclosed in square brackets ([ ]) in the tables identifies areas where
the user needs to type in text instead of selecting from a provided option.
Whenever information is changed (except Date and Time), the systems requires a save
and reboot to take place. Pressing <ESC> discards the changes and boots the system
according to the boot order set from the last boot.
