Product Overview Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
8
2.5 External I/O Connector Locations
The drawing below shows the layout of the rear I/O components for the server board.
AF002161
A
FC D E H
G
B
A PS/2 Mouse E NIC port 2 (1 Gb)
B PS/2 Keyboard F Video
C Serial Port B G USB port 5
D NIC port 1 (1 Gb) H USB port 6
Figure 4. Intel
®
Server Board S5400SF External I/O Layout
