Product Overview Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
6
Table 1. Major Components and Connectors
A Intel
®
RMM2 NIC Connector V Battery
B I/O Module Option Connector W Power Supply Management Connector
C POST Code Diagnostic LEDs X Dual Port USB 2.0 Header (USB0-1)
D PCI Express* Riser Connector (x16 Gen 2) Y SATA0
E System Identification LED - Blue Z SATA1
F System Status LED – Green/Amber AA SATA2
G External I/O Connectors BB SATA3
H FBDIMM Memory Sockets CC SATA4
I Serial ‘B’ Port Configuration Jumper DD SATA5
J Processor 1 Socket EE SATA SW RAID 5 Activation Key Connector
K Processor 2 Socket FF Intel
®
Remote Management Module 2
Connector
L Processor 1 Fan GG Integrated BMC FRU Update Jumper
M Bridge Board Connector HH CMOS Clear Jumper
N SSI 24-pin Control Panel Header II Password Clear Jumper
O Processor 2 Fan JJ Chassis Intrusion Switch Header
P Fan Board Connector KK 3-pin IPMB Header
Q System Fan 2 LL 4-pin IPMB Header
R CPU Power Connector MM System Fan 4
S System Fan 1 NN System Fan 3
T ATA-100 Optical Drive Connector (Power+IO) OO Serial ‘A’ Header
U Main Power Connector
