Intel
®
Server Board S5400SF TPS Product Overview
Revision 2.02
Intel order number: D92944-007
3
2. Product Overview
The Intel
®
Server Board S5400SF is a monolithic printed circuit board with features that were
designed to support the high-density High Performance Computing (HPC) server market.
2.1 Intel
®
Server Board S5400SF Feature Set
Feature Description
Processors 771-pin LGA sockets supporting one or two Intel
®
Xeon
®
processors
Memory 16 Keyed DIMM slots supporting fully buffered DIMM technology (FBDIMM) memory.
Only 240-pin DDR2-667 or DDR2-800 FBDIMMs are supported on this server board.
Chipset
Intel
®
Chipset, which includes the following components:
Intel
®
5400 Memory Controller Hub Chipset
Intel
®
6321ESB I/O Controller Hub
On-board
Connectors/Headers
External I/O connections:
Stacked PS/2 ports for keyboard and mouse
RJ-45 Serial B port
Two RJ-45 NIC connectors for 10/100/1000 Mb connections
Two USB 2.0 ports
Video Connector
Internal connectors/headers:
One USB port header, capable of providing two USB 2.0 ports
One DH-10 Serial A header
Six SATA ports via the Intel
®
6321ESB I/O Controller Hub supporting 3 Gb/s and
integrated Software (SW) RAID 0/1/10 support
One 44pin (power + I/O) ATA/100 connector for optical drive support
One Intel
®
Remote Management Module 2 (Intel
®
RMM2) connector (use of Intel
®
RMM2 is optional)
One Intel
®
I/O Expansion Module connector supporting any of the following:
o Dual GB NIC Intel
®
I/O Expansion Module (Optional)
o External SAS Intel
®
I/O Expansion Module (Optional)
o Infiniband* I/O Expansion Module (Optional)
SSI-compliant 24-pin control panel header
SSI-compliant 24-pin main power connector, supporting the ATX-12 V standard on
the first 20 pins
8-pin +12 V processor power connector
System Fan Support Six 4-pin fan headers supporting two processor fans, and up to four system fans
One 26-pin custom system fan header for use in an Intel
®
Server Chassis
Add-in Adapter Support One full-height riser card slot supporting PCI Express* x16 Gen 2 riser card
On-board Video ATI* ES1000 video controller with 32 MB DDR SDRAM
On-board Hard Drive
Controller
Six Intel
®
6321ESB I/O Controller Hub 3 Gb/s SATA ports
Intel
®
Embedded Server RAID Technology II with SW RAID levels 0/1/10.
Optional support for SW RAID 5 with activation key.
LAN Two 10/100/1000 Intel
®
82563EB PHYs supporting Intel
®
I/O Acceleration Technology
System Management Support for Intel
®
System Management Software 2.0 and later
