Intel
®
Server Board S5400SF TPS Glossary
Revision 2.02
Intel order number: D92944-007
171
Term Definition
MRC Memory Reference Code
ms milliseconds
MTTR Memory Type Range Register
Mux Multiplexor
NIC Network Interface Controller
NMI Non-maskable Interrupt
OBF Output Buffer
OEM Original Equipment Manufacturer
Ohm Unit of electrical resistance
OLTT
Open Loop Throughput Throttling
PAE
Physical Address Extension
PATA Parallel ATA
PCT
Platform Confidence Test
PECI Platform Environmental Control Interface
PEF Platform Event Filtering
PEP Platform Event Paging
PET Platform event trap
PIA Platform Information Area (This feature configures the firmware for the platform hardware)
PIC Programmable Interrupt Controller
PIO Programmable Input/Output
PLD Programmable Logic Device
PMI Platform Management Interrupt
POST Power-On Self Test
PROM Programmable Read-Only Memory
PSMI Power Supply Management Interface
PWM Pulse-Width Modulation
RAM Random Access Memory
RAMDAC Random Access Memory Digital-to-Analog Converter
RAS Reliability, Availability, and Serviceability
RASUM Reliability, Availability, Serviceability, Usability, and Manageability
RISC Reduced Instruction Set Computing
RMM2 Remote Management Module – Second generation
RMM2 NIC Remote Management Module – Second generation dedicated management NIC
ROM Read Only Memory
RTC Real-Time Clock (Component of ICH peripheral chip on the server board)
SCI System Control Interrupt
SDR Sensor Data Record
SECC Single Edge Connector Cartridge
SEEPROM Serial Electrically Erasable Programmable Read-Only Memory
SEL System Event Log
SF Snoop Filter
SHA1 Secure Hash Algorithm Version 1.0
