Intel
®
Server Board S5400SF TPS Appendix D: EFI Shell Commands
Revision 2.02
Intel order number: D92944-007
165
Appendix D: EFI Shell Commands
The embedded EFI Shell must be accessed when running any of the system update utilities or
Platform Confidence Test (PCT). The embedded EFI Shell can be accessed by booting the
system and entering the BIOS Setup utility (F2) during POST. From the BIOS Setup utility Main
menu, tab over to the Boot Manager menu and select EFI Shell.
The following is a list of supported EFI Shell commands. Most shell commands can be invoked
from the EFI shell prompt. However there are several commands that are only available for use
from within batch script files. The following table lists all the commands and provides more
details on each command. The “Batch-only” column indicates if the command is only available
from within script files.
Table 97. EFI Shell Commands
Command Batch-only Description
alias No Displays, creates, or deletes aliases in the EFI shell
attrib No Displays or changes the attributes of files or directories
bcfg No Displays/modifies the driver/boot configuration
break No Executes a debugger break point
cd No Displays or changes the current directory
cls No
Clears the standard output with an optional background
color
comp No Compares the contents of two files
connect No Binds an EFI driver to a device and starts the driver
cp No Copies one or more files/directories to another location
date No Displays the current date or sets the date in the system
dblk No Displays the contents of blocks from a block device
devices No Displays the list of devices being managed by EFI drivers
devtree No
Displays the tree of devices that follow the EFI Driver
Model
dh No Displays the handles in the EFI environment
disconnect No Disconnects one or more drivers from a device
dmem No Displays the contents of memory
dmpstore No Displays all NVRAM variables
drivers No Displays the list of drivers that follow the EFI Driver Model
drvcfg No Invokes the Driver Configuration Protocol
drvdiag No Invokes the Driver Diagnostics Protocol
echo No Displays messages or turns command echoing on or off
edit No Edits an ASCII or UNICODE file in full screen.
EfiCompress No Compress a file
EfiDecompress No Decompress a file
err No Displays or changes the error level
