Regulatory and Certification Information Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
154
Regulatory Compliance Region Marking
PB Free Marking Environmental
Requirements
China RoHS Marking China
China Recycling Package
Marking
(Marked on packaging
label)
China
Other Recycling Package
Marking
(Marked on packaging
label)
Environmental
Requirements
10.2 Electromagnetic Compatibility Notices
10.2.1 FCC (USA)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
For questions related to the EMC performance of this product, contact:
Intel Corporation
5200 N.E. Elam Young Parkway
Hillsboro, OR 97124-6497
1-800-628-8686
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by taking one or more of the
following measures:
Reorient or relocate the receiving antenna.
