Intel
®
Server Board S5400SF TPS Regulatory and Certification Information
Revision 2.02
Intel order number: D92944-007
153
(MDDS) must be produced to illustrate compliance. Due verification of random materials is
required as a screening/audit to verify suppliers declarations.
The server board complies with the following ecology regulatory requirements:
All materials, parts and subassemblies must not contain restricted materials as defined
in Intel’s Environmental Product Content Specification of Suppliers and Outsourced
Manufacturers – http://supplier.intel.com/ehs/environmental.htm
.
Europe - European Directive 2002/95/EC - Restriction of Hazardous Substances (RoHS)
Threshold limits and banned substances are noted below.
Quantity limit of 0.1% by mass (1000 PPM) for Lead, Mercury, Hexavalent Chromium,
Polybrominated Biphenyls Diphenyl Ethers (PBB/PBDE)
Quantity limit of 0.01% by mass (100 PPM) for Cadmium
China RoHS
All plastic parts that weigh >25 gm shall be marked with the ISO11469 requirements for
recycling. Example >PC/ABS<
EU Packaging Directive
German Green Dot
Japan Recycling
10.1.5 Product Regulatory Compliance Markings
Regulatory Compliance Region Marking
UL Mark USA/Canada
CE Mark Europe
EMC Mark Canada
CANADA ICES-003 CLASS A
CANADA NMB-003 CLASSE A
D33025
BSMI Marking Taiwan
Ctick Marking Australia/New
Zealand
RRL MIC Mark Korea
인증번호: CPU-X38ML (A)
Country of Origin Marking
(Marked on packaging
label)
Exporting
Requirements Made in xxxxx
