Connector/Header Locations and Pin-outs Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
130
6.7.7 Keyboard and Mouse Connector
Two stacked PS/2 ports (J9A1) are provided to support both a keyboard and a mouse. Either
PS/2 port can support a mouse or keyboard. The following table details the pin-out of the PS/2
connector.
Table 75. Stacked PS/2 Keyboard and Mouse Port Pin-out (J9A1)
Pin Signal Name Description
1 KB_DATA_F Keyboard Data
2 TP_PS2_2 Test point – keyboard
3 GND Ground
4 P5V_KB_F Keyboard/mouse power
5 KB_CLK_F Keyboard Clock
6 TP_PS2_6 Test point – keyboard/mouse
7 MS_DAT_F Mouse Data
8 TP_PS2_8 Test point – keyboard/mouse
9 GND Ground
10 P5V_KB_F Keyboard/mouse power
11 MS_CLK_F Mouse Clock
12 TP_PS2_12 Test point – keyboard/mouse
13 GND Ground
14 GND Ground
15 GND Ground
16 GND Ground
17 GND Ground
6.7.8 USB 2.0 Connectors
The following table details the pin-out of the externally stacked USB connectors found on the
back edge of the server board:
Table 76. External USB Connector Pin-out (J5A1)
Pin Signal Name Description
1 USB_OC5_FB_1 USB_Port5_PWR
2 USB_P5N_FB_2 DATAL0_Port5 (Differential data line paired with DATAH0)
3 USB_P5P_FB_3 DATAH0_Port5 (Differential data line paired with DATAL0)
4 GND Ground
5 USB_OC6_FB_5 USB_Port6_PWR
6 USB_P6N_FB_6 DATAL0_Port6 (Differential data line paired with DATAH0)
7 USB_P6P_FB_7 DATAH0_Port6 (Differential data line paired with DATAL0)
8 GND Ground
One 2x5 header on the server board (J1J1) provides an option to support two additional USB
2.0 ports. The pin-out of the connector is detailed in the following table.
