Color State System Status Description
Amber ~1 Hz blink Non-Fatal Non-fatal alarm – system is likely to fail:
BIOS Detected
1. In a non-sparing and non-mirroring mode if the threshold of ten
correctable errors is crossed within the window
1
.
2. PCI Express* uncorrectable link errors.
Integrated BMC Detected
1. Critical threshold crossed – Voltage, temperature, power nozzle,
power gauge, and PROCHOT (Therm Ctrl) sensors.
2. VRD Hot asserted
3. Minimum number of fans to cool the system are not present or
have failed.
Amber Solid on Fatal Fatal alarm – system has failed or shutdown:
BIOS Detected
1. DIMM failure when there is one DIMM present and no good
memory is present
1
.
2. Run-time memory uncorrectable error in a non-redundant mode
1
.
3. CPU configuration error (for instance, processor stepping
mismatch).
Integrated BMC Detected
1. CPU IERR signal asserted.
2. CPU 1 is missing.
3. CPU THERMTRIP.
4. No power good – power fault.
5. Power Unit Redundancy sensor – Insufficient resources offset
(indicates not enough power supplies present).
Off N/A Not ready AC power off
Note:
1. BIOS detects these conditions and sends a Set Fault Indication command to the
Integrated BMC to provide
a contribution to the system status LED.
2. Support for upper non-critical limit is not provided in default SDR configuration. However if a user does
enable this threshold in the SDR, then the system status LED should behave as described.
6.5.7 Chassis ID LED
The chassis ID LED provides a visual indication of a system being serviced. The state of the
chassis ID LED is affected by the following:
It is toggled by the chassis ID button.
It can be controlled by the Chassis Identify command (IPMI).
It can be controlled by the Chassis Identify LED command (OEM).
Table 66. Chassis ID LED Indicator States
State LED State
Identify active via button Solid on
Identify active via command ~1 Hz blink
Off Off
