Intel
®
Server Board S5400SF TPS Connector/Header Locations and Pin-outs
Revision 2.02
Intel order number: D92944-007
121
Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal
3 RSVD 3 12V
2 12V 2 12V
1 12V 1 PRSNT1#
6.5 SSI Control Panel Connector (J3H2)
The server board provides a 24-pin SSI control panel connector (J3H2) for use with non-Intel
chassis. The following table provides the pin-out for this connector.
Table 63. SSI Standard 24-pin Control Panel Connector Pin-out (J3H2)
Pin Signal Name Pin Signal Name
1 P3V3_STBY 2 P3V3_STBY
3 Key 4 P5V_STBY
5 FP_PWR_LED 6 FP_ID_LED
7 P3V3 8 LED_STATUS_GREEN
9 HDD_LED_ACT 10 LED_STATUS_AMBER
11 FP_PWR_BTN 12 NIC1_ACT_LED
13 GND 14 NIC1_LINK_LED
15 BMC Reset Button 16 SMB_SN_3V3SB_DAT
17 GND 18 SMB_SN_3V3SB_CLK
19 FP_ID_BTN 20 FP_CHASSIS_INTRU
21 TEMP_SENSOR 22 NIC2_ACT_LED
23 FP_NMI_BTN 24 NIC2_LINK_LED
The system BIOS combined with the Integrated BMC provide the functionality of the various
supported control panel buttons and LEDs. The following sections describe the supported
functionality of each control panel feature.
Note: Control panel features are also routed through the bridge board connector at location
J4G1, as is implemented in Intel
®
Server Systems configured using a bridge board and a hot-
swap backplane.
6.5.1 Power Button
The BIOS supports a front control panel power button. Pressing the power button initiates a
request that the Integrated BMC forwards to the ACPI power state machines in the chipset. It is
monitored by the Integrated BMC and does not directly control power on the power supply.
Power Button — Off to On
The Integrated BMC monitors the power button and the wake-up event signals from the
chipset. A transition from either source results in the Integrated BMC starting the power-
up sequence. Since the processors are not executing, the BIOS does not participate in
this sequence. The hardware receives the power good and reset signals from the
Integrated BMC and then transitions to an ON state.
