Connector/Header Locations and Pin-outs Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
120
Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal
45 HSOP7 45 GND
44 GND 44 HSIN6
43 GND 43 HSIP6
42 HSON6 42 GND
41 HSOP6 41 GND
40 GND 40 HSIN5
39 GND 39 HSIP5
38 HSON5 38 GND
37 HSOP5 37 GND
36 GND 36 HSIN4
35 GND 35 HSIP4
34 HSON4 34 GND
33 HSOP4 33 RSVD
32 GND 32 RSVD
31 PRSNT2# 31 GND
30 RSVD 30 HSIN3
29 GND 29 HSIP3
28 HSON3 28 GND
27 HSOP3 27 GND
26 GND 26 HSIN2
25 GND 25 HSIP2
24 HSON2 24 GND
23 HSOP2 23 GND
22 GND 22 HSIN1
21 GND 21 HSIP1
20 HSON1 20 GND
19 HSOP1 19 RSVD
18 GND 18 GND
17 PRSNT2# 17 HSIN0
16 GND 16 HSIP0
15 HSON0 15 GND
14 HSOP0 14 REFCLK-
13 GND 13 REFCLK+
12 RSVD 12 GND
KEY KEY
KEY KEY
11 WAKE# 11 PWRGD
10 3.3V AUX 10 3.3V
9 JTAG1 9 3.3V
8 3.3V 8 JTAG5
7 GND 7 JTAG4
6 SMDAT 6 JTAG3
5 SMCLK 5 JTAG2
4 GND 4 GND
