Intel
®
Server Board S5400SF TPS Connector/Header Locations and Pin-outs
Revision 2.02
Intel order number: D92944-007
119
6.4 Riser Card Slot
The server board has one riser card slot capable of supporting PCI Express* x16 Gen 2 riser
card. The following table shows the pin-out for this riser slot.
Table 62. Riser Card Slot Pin-out (J4B1)
Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal
82 RSVD 82 GND
81 PRSNT2# 81 HSIN15
80 GND 80 HSIP15
79 HSON15 79 GND
78 HSOP15 78 GND
77 GND 77 HSIN14
76 GND 76 HSIP14
75 HSON14 75 GND
74 HSOP14 74 GND
73 GND 73 HSIN13
72 GND 72 HSIP13
71 HSON13 71 GND
70 HSOP13 70 GND
69 GND 69 HSIN12
68 GND 68 HSIP12
67 HSON12 67 GND
66 HSOP12 66 GND
65 GND 65 HSIN11
64 GND 64 HSIP11
63 HSON11 63 GND
62 HSOP11 62 GND
61 GND 61 HSIN10
60 GND 60 HSIP10
59 HSON10 59 GND
58 HSOP10 58 GND
57 GND 57 HSIN9
56 GND 56 HSIP9
55 HSON9 55 GND
54 HSOP9 54 GND
53 GND 53 HSIN8
52 GND 52 HSIP8
51 HSON8 51 GND
50 HSOP8 50 RSVD
49 GND 49 GND
48 PRSNT2# 48 HSIN7
47 GND 47 HSIP7
46 HSON7 46 GND
