Connector/Header Locations and Pin-outs Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
118
6.3.2 Intel
®
RMM2 NIC Connector (J1B2)
The server board provides an internal 30-pin mezzanine style connector (J1B2) to
accommodate a proprietary form factor Intel
®
RMM2 NIC module. The following table details the
pin-out of the Intel
®
RMM2 NIC module connector.
Table 59. 30-pin Intel
®
RMM2 NIC Module Connector Pin-out (J1B2)
Pin Signal Name Pin Signal Name
1 FM_MAN_LAN_TYPE2 2 MII_MDC_RMII_SPARE
3 FM_MAN_LAN_TYPE1 4 MII_COL_RMIIB_RXER
5 GND 6 GND
7 MII_TXCLK_RMIIB_RXCLK 8 MII_TXER_RMIIB_TXEN
9 MII_CRS_RMIIB_CRS 10 MII_MDIO_RMIIB_PRESENT
11 GND 12 GND
13 MII_TXD2_RMIIB_TXD0 14 MII_RXD3_RMIIB_RXD1
15 MII_TXD1_RMIIA_TXD1 16 MII_RXD3_RMIIB_RXD0
17 GND 18 GND
19 MII_TXD3_RMIIB_TXD1 20 MII_RXD1_RMIIA_RXD1
21 MII_TXD0_RMIIA_TXD0 22 MII_RXD0_RMIIA_RXD0
23 GND 24 GND
25 MII_TXEN_RMIIA_TXEN 26 MII_RXCLK
27 P3V3_AUX 28 P3V3_AUX
29 MII_RXER_RMIIA_RXER 30 MII_RXDV_RMIIA_CRS
6.3.3 IPMB Headers (J1C3, J1C4)
Table 60. IPMB Header Pin-out (J1C3)
Pin Signal Name Description
1 SMB_IPMB_5VSB_DAT BMC IMB 5V Standby Data Line
2 GND Ground
3 SMB_IPMB_5VSB_CLK BMC IMB 5V Standby Clock Line
4 P5V_STBY +5V Standby Power
Table 61. IPMB Header Pin-out (J1C4)
Pin Signal Name Description
1 SMB_IPMB_5VSB_DAT BMC IMB 5V Standby Data Line
2 GND
3 SMB_IPMB_5VSB_CLK BMC IMB 5V Standby Clock Line
