Connector/Header Locations and Pin-outs Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
116
Table 57. Power Supply Signal Connector Pin-out (J1K1)
Pin Signal Color
1 SMB_CLK_ESB_FP_PWR_R Orange
2 SMB_DAT_ESB_FP_PWR_R Black
3 SMB_ALRT_3_ESB_R Red
4 3.3V SENSE- Yellow
5 3.3V SENSE+ Green
6.3 System Management Headers
6.3.1 Intel
®
Remote Management Module 2 (Intel
®
RMM2) Connector (J1C2)
A 120-pin Intel
®
RMM2 Connector (J1C2) is included on the server board for sole support of the
optional Intel
®
Remote Management Module 2. There is no support for third-party ASMI cards
on this server board.
Note: Only the Intel
®
Remote Management Module 2 (Intel Product Code: AXXRMM2) is
supported with this server board.
Table 58. Intel
®
RMM2 Connector Pin-out (J1C2)
Pin Signal Name Pin Signal Name
1 Reserved - NC 2 GND
3 ESB_PLT_RST_G1_N 4 Reserved - NC
5 GND 6 Reserved - NC
7 Reserved - NC 8 GND
9 Reserved - NC 10 GND
11 GND 12 Reserved - NC
13 GND 14 IRQ_SERIAL_R
15 USB_ESB_P7P 16 GND
17 USB_ESB_P7N 18 GND
19 GND 20 Reserved - NC
21 P3V3 22 Reserved - NC
23 LPC_LAD<0> 24 GND
25 LPC_LAD<1> 26 LPC_FRAME_N
27 P3V3 28 LPC_LAD<2>
29 LPC_LCLK 30 LPC_LAD<3>
31 P3V3 32 P3V3
33 SMB_1_3V3SB_MS_DAT 34 SMB_IPMB_3V3SB_DAT
35 SMB_1_3V3SB_SL_DAT 36 SMB_IPMB_3V3SB_CLK
37 SMB_1_3V3SB_MS_CLK 38 SMB_0_3V3SB_MS_CLK
39 SMB_1_3V3SB_INT 40 SMB_0_3V3SB_INT
41 P3V3_AUX 42 SMB_0_3V3SB_MS_DAT
43 SPB_IMM_DSR_N 44 SMB_0_3V3SB_SL_DAT
45 SPB_IMM_RTS_N 46 P3V3_AUX
