System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
108
Table 51. Setup Utility — Boot Manager Screen Fields
Setup Item Options Help Text Comments
Launch EFI Shell Select this option to boot now.
Note: This list is not the system boot
option order. Use the Boot Options
menu to view and configure the system
boot option order.
Boot Device #x Select this option to boot now.
Note: This list is not the system boot
option order. Use the Boot Options
menu to view and configure the system
boot option order.
5.2.3.8 Error Manager Screen
The Error Manager screen displays any errors encountered during POST.
Error Manager Exit
ERROR CODE SEVERITY INSTANCE
Figure 39. Setup Utility — Error Manager Screen Display
Table 52. Setup Utility — Error Manager Screen Fields
Setup Item Options Help Text Comments
Displays System Errors Information only. Displays errors that
occurred during this POST.
5.2.3.9 Exit Screen
The Exit screen allows the user to choose whether to save or discard the configuration changes
made on the other screens. It also provides a method to restore the server to the factory
defaults or to save or restore a set of user-defined default values. If Load Default Values is
selected, the default settings, noted in bold in the tables in this chapter, are applied. If Load
User Default Values is selected, the system is restored to the default values that the user saved
earlier, instead of being restored to the factory defaults.
