Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
107
Boot Options
BEV Device #1 <Available BEV devices>
BEV Device #2 <Available BEV devices>
Figure 37. Setup Utility — BEV Device Order Screen Display
Table 50. Setup Utility — BEV Device Order Fields
Setup Item Options Help Text Comments
BEV Device #1 Available BEV
devices
Set the Bootstrap Entry Vector (BEV) device
boot order by selecting the boot option for this
position.
BEV devices require their own proprietary
method to load an OS using a bootable option
ROM. BEV devices are typically found on
remote program load devices.
BEV Device #2 Available BEV
devices
Set the Bootstrap Entry Vector (BEV) device
boot order by selecting the boot option for this
position.
BEV devices require their own proprietary
method to load an OS using a bootable option
ROM. BEV devices are typically found on
remote program load devices.
5.2.3.7 Boot Manager Screen
The Boot Manager screen displays a list of devices available for booting, and allows the user to
select a boot device for immediately booting the system.
To access this screen from the Main screen, choose Boot Manager.
Main
Advance
d
Security Server Management Boot Options Boot Manager
<Boot device #1>
<Boot Option #x>
[EFI Shell]
Figure 38. Setup Utility — Boot Manager Screen Display
