Table 48. Setup Utility — Floppy Order Fields
Setup Item Options Help Text Comments
Floppy Disk #1 Available floppy
disk
Set floppy disk boot order by selecting the
boot option for this position.
Floppy Disk #2 Available floppy
disk
Set floppy disk boot order by selecting the
boot option for this position.
5.2.3.6.4 Network Device Order Screen
The Network Device Order screen allows the user to control the network bootable devices.
To access this screen from the Main screen, choose Boot Options > Network Device Order.
Boot Options
Network Device #1
<Available Network devices>
Network Device #2
<Available Network devices>
Figure 36. Setup Utility — Network Device Order Screen Display
Table 49. Setup Utility — Network Device Order Fields
Setup Item Options Help Text Comments
Network Device #1 Available
network devices
Set network device boot order by selecting the
boot option for this position. Add-in or onboard
network devices with a PXE option ROM are
two examples of network boot devices.
Network Device #2 Available
network devices
Set network device boot order by selecting the
boot option for this position. Add-in or onboard
network devices with a PXE option ROM are
two examples of network boot devices.
5.2.3.6.5 BEV Device Order Screen
The BEV Device Order screen allows the user to control the BEV bootable devices.
To access this screen from the Main screen, choose Boot Options > BEV Device Order.
