Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
103
Main
Advance
d
Security Server Management Boot Options Boot Manager
Boot Timeout
<0 - 65535>
Boot Option #1
<Available Boot devices>
Boot Option #2
<Available Boot devices>
Boot Option #x
<Available Boot devices>
Boot Option Retry
Enabled/Disabled
Hard Disk Order
CDROM Order
Floppy Order
Network Device Order
BEV Device Order
Figure 32. Setup Utility — Boot Options Screen Display
Table 45. Setup Utility — Boot Options Screen Fields
Setup Item Options Help Text Comments
Boot Timeout
0 - 65535
The number of seconds BIOS pauses
at the end of POST to allow the user to
press the [F2] key for entering the
BIOS Setup utility.
Valid values are 0-65535. Zero is the
default. A value of 65535 causes the
system to go to the Boot Manager
menu and wait for user input for every
system boot.
After entering the desired
timeout, press enter to
register that timeout value to
the system. These settings
are in seconds.
Boot Option #x Available boot
devices.
Set system boot order by selecting the
boot option for this position.
Note: The EFI Shell boot
option can only be set as
the first or last boot option in
the list.
Boot Option Retry Enabled
Disabled
This continually retries non-EFI based
boot options without waiting for user
input.
Hard Disk Order Set hard disk boot order by selecting
the boot option for this position.
Appears when more than
one hard disk drive is
available in the system.
CDROM Order Set CD-ROM boot order by selecting
the boot option for this position.
Appears when more than
one CD-ROM drive is
available in the system.
