Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
101
Table 43. Setup Utility — Console Redirection Configuration Fields
Setup Item Options Help Text Comments
Console Redirection Disabled
Serial A
Serial B
Console redirection allows a serial port to be used for
server management tasks.
[Disabled] - No console redirection.
[Serial Port A] - Configure serial port A for console
redirection.
[Serial Port B] - Configure serial port B for console
redirection.
Enabling this option disables display of the Quiet Boot
logo screen during POST.
Flow Control None
RTS/CTS
Flow control is the handshake protocol.
Setting must match the remote terminal application.
[None] - Configure for no flow control.
[RTS/CTS] - Configure for hardware flow control.
Baud Rate 9600
19.2K
38.4K
57.6K
115.2K
Serial port transmission speed. Setting must match
the remote terminal application.
Terminal Type PC-ANSI
VT100
VT100+
VT-UTF8
Character formatting used for console redirection.
Setting must match the remote terminal application.
Legacy OS
Redirection
Disabled
Enabled
This option enables legacy OS redirection (i.e., DOS)
on the serial port. If it is enabled, the associated serial
port is hidden from the legacy OS.
5.2.3.5 Server Management System Information Screen
The Server Management System Information screen allows the user to view part numbers,
serial numbers, and firmware revisions.
To access this screen from the Main screen, choose Server Management > System Information.
