Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
99
Main
Advance
d
Security Server Management Boot Options Boot Manager
Assert NMI on SERR
Enabled/Disabled
Assert NMI on PERR
Enabled/Disabled
Resume on AC Power Loss
Stay Off /Last state/ Reset
Clear System Event Log
Enabled/Disabled
Windows Hardware Error Architecture
Enabled/Disabled
FRB-2 Enable
Enabled/Disabled
O/S Boot Watchdog Timer
Enabled/Disabled
O/S Boot Watchdog Timer Policy
Power off/Reset
O/S Boot Watchdog Timer Timeout
5 minutes/10 minutes/15 minutes/20 minutes
Plug-n-Play BMC Detection Enable/Disabled
► Console Redirection
► System Information
Figure 29. Setup Utility — Server Management Configuration Screen Display
Table 42. Setup Utility — Server Management Configuration Screen Fields
Setup Item Options Help Text Comments
Assert NMI on SERR
Enabled
Disabled
On SERR, generate an NMI and log an error.
Note: Enabled must be selected for the Assert NMI on
PERR setup option to be visible.
Assert NMI on PERR
Enabled
Disabled
On PERR, generate an NMI and log an error.
Note: This option is only active if the Assert NMI on
SERR option is Enabled.
Resume on AC Power
Loss
Stay Off
Last state
Reset
System action to take on AC power loss recovery.
[Stay Off] - System stays off.
[Last State] - System returns to the same state before
the AC power loss.
[Reset] - System powers on.
Clear System Event
Log
Enabled
Disabled
Clears the System Event Log. All current entries are
lost.
Note: This option is reset to [Disabled] after a reboot.
Windows Hardware
Error Architecture
Enabled
Disabled
During HW errors, in addition to the BIOS SMI Error
Handlers, OS Error Handlers are signaled.
