System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
98
Table 41. Setup Utility — Security Configuration Screen Fields
Setup Item Options Help Text Comments
Administrator Password
Status
<Installed
Not Installed>
Information only. Indicates
the status of the
administrator password.
User Password Status <Installed
Not Installed>
Information only. Indicates
the status of the user
password.
Set Administrator
Password
[123abcd] Administrator password is used to
control change access in the BIOS
Setup utility.
Only alphanumeric characters can be
used. Maximum length is 7 characters. It
is case sensitive.
Note: Administrator password must be
set in order to use the user account.
This option is only to control
access to setup.
Administrator has full
access to all setup items.
Clearing the Administrator
password also clears the
user password.
Set User Password [123abcd] User password is used to control entry
access to the BIOS Setup utility.
Only alphanumeric characters can be
used. Maximum length is 7 characters. It
is case sensitive.
Note: Removing the administrator
password also automatically removes
the user password.
Available only if the
Administrator Password is
installed. This option only
protects the setup. The user
password only has limited
access to setup items.
Front Panel Lockout Enabled
Disabled
Locks the power button and reset button
on the system's front panel. If [Enabled]
is selected, power and reset must be
controlled via a system management
interface.
5.2.3.4 Server Management Screen
The Server Management screen provides fields to configure several server management
features. It also provides an access point to the screens for configuring console redirection and
displaying system information.
To access this screen from the Main screen, choose Server Management.
