System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
96
Setup Item Options Help Text Comments
Onboard Video
Enabled
Disabled
On-board video controller.
Warning: The system video is completely
disabled if this option is disabled and an add-in
video adapter is not installed.
When disabled, the system
requires an add-in video
card in order for video to
be seen.
Dual Monitor Video Enabled
Disabled
Both the on-board video controller and an add-in
video adapter are enabled for system video. The
on-board video controller is the primary video
device.
Onboard NIC ROM
Enabled
Disabled
Load the embedded option ROM for the on-board
network controllers.
Warning: If [Disabled] is selected, NIC1 and NIC2
can not be used to boot or wake the system.
I/O Module NIC ROM Enabled
Disabled
Load the embedded option ROM for the on-board
network controller on the I/O module.
Option only displays when
a optional Dual GigE I/O
Module is Installed
NIC 1 MAC Address No entry
allowed
Information only. 12 hex
digits of the MAC address.
NIC 2 MAC Address No entry
allowed
Information only. 12 hex
digits of the MAC address.
Intel
®
I/OAT Enabled
Disabled
Intel
®
I/O Acceleration Technology 2 (I/OAT2)
accelerates TCP/IP processing for on-board NICs,
delivers data-movement efficiencies across the
entire server platform, and minimizes system
overhead.
5.2.3.2.8 System Acoustic and Performance Configuration
The System Acoustic and Performance Configuration screen provides fields to configure the
thermal characteristics of the system.
To access this screen from the Main screen, choose Advanced > System Acoustic and
Performance Configuration.
Advanced
System Acoustic and Performance Configuration
Throttling Mode Closed Loop/Open Loop
Altitude 300m or less/301m-900m/Higher than 900m
Figure 27. Setup Utility — System Acoustic and Performance Configuration
